Eaton Wiring Devices 7500 7501W-JP-C Rocker Switch, 15 A, 120/277 V, SPST, Lead Wire Terminal, White

Eaton Wiring Devices

Eaton Wiring Devices 7500 7501W-JP-C Rocker Switch, 15 A, 120/277 V, SPST, Lead Wire Terminal, White

$35.45$35.45
Eaton Wiring Devices 7500 7501W-JP-C Rocker Switch, 15 A, 120/277 V, SPST, Lead Wire Terminal, White
  • Color: White
  • Contact Configuration: SPST
  • Current Rating: 15 A
  • Dimensions: 4.19 in L x 1.44 in W x 0.97 in D
  • Housing Material: Thermoplastic
  • Model #: 7501W-C-10-L
  • UPC #: 032664643590
  • SKU: 9233511

Your shopping list will be used for pickup in-store

Product Details

Ultrasonic welding and integrated construction of the strap and body. Backwire clamps on the side terminals for installation of #12 and #14 wire. Thermoplastic rocker, top and back body are virtually unbreakable. Screws accept slotted, Phillips and Robertson head tools for installation in both the USA and Canada. Longer, wider strap provides 40% more contact area to wall board. Virtually eliminates floating installations. Built-in wire stripper for #12 and #14 wire. Stippled ground screw standard. 15 A, 120/277 VAC rating for fluorescent lighting fixtures typical in commercial applications. Push in terminals accept #14 solid wire only. Temperature rating of -20 to 60 deg C. Meets flammability requirements per UL 94, 6504, V2 rated, VO rated. UL and cUL listed, meets all UL20 requirements.

Key Features

  • Thermoplastic rocker, top and back body are virtually unbreakable to deliver years of durable performance
  • Ultrasonic welding and integrated construction of the strap and body provide great ground integrity even under heavy use
  • Backwire clamps on side terminals provide for easy installation of #12 and #14 AWG wire
  • Push-in terminals accept #14 AWG solid wire for quick installation
  • Stippled ground screw terminal standard
  • Long, broad mounting strap virtually eliminates floating installations
  • Patented built-in wire stripper for #14 and #12 AWG wire to speed installation
  • Tri-combo screws accept Slotted, Phillips and Robertson-head tools for installation flexibility
  • Lighted switches glow in OFF position
  • Redesigned paddle for easier actuation and quiet operation

Item Specifications

ColorWhite
Contact ConfigurationSPST
Current Rating15 A
Dimensions4.19 in L x 1.44 in W x 0.97 in D
Housing MaterialThermoplastic
Includes(1) Metal Strap
Mounting TypeStrap
Temperature Rating-20 to 60 deg C
Terminal TypeLead Wire
Voltage Rating120/277 V
